General

Total length (mm)

8995

Total width (mm)

2430

Total height (mm)

330

Wheel base (mm)

4300

Maximum gross weight (kg)

12600

Number of passenger (person)

24-38

Configuration

Engine

Engine with MAN Technology

MC07.28/MC07.24

EV Drive system

Electric control system

SINONTRUK

Rated power （KW)

206/176

Drive motor

permanent magnet synchronous motor

Emission

Euro III-Euro V

Rated/Peak power

80/160

Clutch

Diaphragm φ395mm thrust

Battery capacity

210.5

Transmission box

6-gear MT

Cruising (km)

400 (Uniform speed)

Description

standard

Optional

Axle

front disc and rear drum

front disc and rear disc

Suspension

Leaf spring

Air suspension, imported air spring

Heating system

Defroster

Independent heating system

Air conditioning system

22,000 kcal

24,000 kcal

Audio-Video system

MP3 radio player

HD player + front ceiling 19" fixed LCD display + Microphone
